Equipment Introduction

The Handheld Laser Welding Machine is a core equipment for flexible and efficient welding in sheet metal companies. It can customize non-standard equipment for industries like office furniture, kitchen & bathroom appliances, auto-motorcycle parts, etc. With lightweight handheld design, easy-to-operate features and high-quality welding effect as the core, it solves the pain points of traditional welding equipment such as poor flexibility, difficult operation for novices and tedious subsequent processes, realizing flexible, easy-to-operate and low-follow-up-cost sheet metal welding to meet enterprises' diversified welding scenario needs.​

Product Advantages

Product show

Working Principle

Flexible welding control — The operator holds the welding gun, adjusts the angle and position according to the welding part; the laser generator produces high-energy laser, which is focused on the welding joint through the gun head to melt metal and form a weld, realizing flexible welding at any angle.​
Easy-to-operate and efficient welding — Simplified operation interface allows inexperienced personnel to master it through basic guidance; under continuous welding mode, laser outputs stably and continuously to form smooth welds, reducing subsequent grinding processes and improving overall efficiency.​
High-quality leak-proof guarantee — Concentrated laser energy results in small welding affected area, reducing workpiece deformation; manual seamless continuous welding ensures tight welds, forming effective sealing for container products, achieving excellent leak-proof effect and guaranteeing welding quality.

Specifications - Technical Data

Machine Model15002000
Laser Rated Output Power1500w2000w
Central Wavelength1080nm±5
Power Adjustable Range1-100%
Power Stability±2
Maximum Modulation Frequency1-5000HZ
Operating Voltage and Frequency50/60HZ
Control ModeRS-232/AD
Connector TypeQBH
Air Pressure Requirement1.2MPa
Operating EnvironmentFlat Surface, No Vibration Sources, 13°C-40°C, Humidity 5%-75%

More applications

Customized Production Line Design, Full-Lifecycle Service Guarantee From Solution to Implementation, Empowering Enterprises to Reduce Costs, Boost Efficiency, and Achieve Zero Risks!

OFFICE FURNITURE

TOOL CABINET

MEDICAL DEVICES
